Features
- A compact and easy operate Ultrasonic Bath manufactured with advanced MOSFET technology.
- Designed to clean small and dismantled intricate parts at an operating frequency range of 37 KHz ± 3 kHz.
- Fitted with Microprocessor Based Digital Temperature Indicator-Cum-Controller at any temperature from ambient +5°C to 60°C.
- Also fitted with digital timer with settable range from 0-15 min or 0-30 min (depending upon the capacity ordered).
- Extensively protected electronic circuits means longer and safer operations.
- High frequency electrical energy is converted into ultrasound waves by means of ULTRSONIC TRANSDUCERS.
- Compact, rugged and highly durable system.
- Efficiency of 90% permits maximum cleaning action, low power consumption.
- Extensively protected electronic circuits means longer and safer operations.
- Automatic frequency tuning for maximum output.
- Input range of 170VAC-270VAC, highest immunity to input supply variations.
- Pre-set Auto Degassing function.
- Pulse Sweep Power for better effective cleaning.
- To work on 220/230 V AC Supply.
Technical Specifications & Ordering Informations
| Model | #UCB-20 | #UCB-35 | #UCB-50 | #UCB-70 | #UCB-100 | #UCB-200 | #UCB-250 | #UCB-300 | #UCB-500 | #UCB-1000 |
|---|---|---|---|---|---|---|---|---|---|---|
| Capacity | 2.0 ltrs | 3.5 ltrs | 5.0 ltrs | 7.0 ltrs | 10.0 ltrs | 20.0 ltrs | 25.0 ltrs | 30.0 ltrs | 50.0 ltrs | 100.0 ltrs |
| Time Setting | 1-30 mins | |||||||||
| Heating Temp. | Ambient +5°C to 60°C | |||||||||
| Display | LED | |||||||||
| Frequency | 37 KHz ± 3 kHz | |||||||||
| Lid Material | SS-304 | |||||||||
| Inner Tank Material | SS-304 | |||||||||
| Outer Tank Material | SS-304 | |||||||||
| Power Supply | AC 220V | |||||||||
