ULTRA HIGH PRESSURE AUTOCLAVE VERTICAL (CEMENT AUTOCLAVE) LEW-105

Designed for research and industrial Application where high temperature and high pressure condition are required.

SKU: LEW-105 Category:

Features

  • Outer body made of CRC sheet duly powder coated.
  • Inner cylinder is made of heavy gauge welded Stainless Steel Sheet.
  • Lid is made of thick Stainless Steel plate.
  • Lid is closed through nut locking arrangement.
  • Working Pressure range up to 300 psi (21± 1kg/cm²).
  • Temperature range up to 215°C.
  • Highly accurate and reliable RTD (Pt-100) sensor for accurate temperature control.
  • User settable Digital Temperature Indicator cum Controller is fitted for automatic control with respect to time and temperature.
  • User settable in-built digital buzzer timer in minutes for automatic control of sterilization time.
  • Manual purging (exhaust of pressure) at cycle end, on the sound of the audio buzzer.
  • Fitted with a safety valve as a safety device.
  • Fitted with a vacuum breaker to break vacuum in case of formation of vacuum due to steam condensation.
  • Fitted with Automatic Pressure Control Switch for double safety, in case Digital Temperature Controller fails.
  • Provided with double safety valve protection.
  • Fitted with a reliable pressure gauge.

Technical Specifications & Ordering Informations

Model INNER DIMENSION (DIA X HT)
#UHPAV-22 250 x 450 mm
